SN74LS393NS
RoHS
/
Package 14-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
Tube Active e4 74LS393 logic counter 60ns 5.3mm 5V 0.008A
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.32352
≥100 USD $1.24872
≥500 USD $1.06392
≥1000 USD $0.999011
≥3000 USD $0.874139
Inventory: 749
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Length 10.3mm
Technical
Count Rate 35MHz
Propagation Delay (tpd) 60 ns
Trigger Type Negative Edge
Prop. Delay@Nom-Sup 60 ns
Number of Bits per Element 4
Max I(ol) 0.008 A
Logic Type Binary Counter
Direction Up
Family LS
Reset Asynchronous
Load Capacitance 15pF
Power Supplies 5V
Number of Elements 2
Qualification Status Not Qualified
Pin Count 14
Base Part Number 74LS393
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Packing Method TR
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
