CD74HCT393MTG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
IC DUAL 4-STG BIN COUNTER 14SOIC
PDF
/
Inventory: 4513
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Clock Edge Trigger Type Negative Edge
fmax-Min 18 MHz
Propagation Delay (tpd) 93 ns
Direction Unidirectional
Logic Function Counter
Family HCT
Reset Asynchronous
Number of Bits 4
Load Capacitance 50pF
Temperature Grade MILITARY
Power Supplies 5V
Number of Elements 2
Operating Supply Voltage 5.5V
Pin Count 14
Frequency 27MHz
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case SOIC
Mount Surface Mount
