MC14516BFELG
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Counters, Dividers
Description
GULL WING DUAL POSITIVE EDGE BIDIRECTIONAL divider circuit 125C 4MHz 18V 5.275mm
PDF
/
Inventory: 9592
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.275mm
Length 10.2mm
Height Seated (Max) 2.05mm
Technical
Mode of Operation SYNCHRONOUS
Load/Preset Input YES
Count Direction BIDIRECTIONAL
fmax-Min 4 MHz
Propagation Delay (tpd) 630 ns
Trigger Type POSITIVE EDGE
Logic IC Type BINARY COUNTER
Family 4000/14000/40000
Number of Bits 8
Supply Voltage-Min (Vsup) 3V
Temperature Grade MILITARY
Operating Supply Voltage 18V
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Number of Terminations 16
Physical
Number of Pins 16
Surface Mount YES
