MC10H166FNR2
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
TWO OUTPUT PROVIDES: A < B; A > B AND A = B FUNCTIONS Tape & Reel (TR) 10H e0 digital comparator 50mA 50mA 3.7ns 1.27mm 3.7ns @ -5.2V -
PDF
/
Buying Options
Total Price: USD $3.42
Unit Price: USD $3.4232
≥1 USD $3.4232
Inventory: 553
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~75°C
Packaging Tape & Reel (TR)
Series 10H
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type Magnitude Comparator
Terminal Finish TIN LEAD
Additional Feature TWO OUTPUT PROVIDES: A < B; A > B AND A = B FUNCTIONS
Technology ECL
Voltage - Supply -4.94V~-5.46V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Output Active High
Pin Count 20
JESD-30 Code S-PQCC-J20
Qualification Status COMMERCIAL
Number of Bits 5
Family 10H
Current - Output High, Low 50mA 50mA
Max Propagation Delay @ V, Max CL 3.7ns @ -5.2V, -
Propagation Delay (tpd) 3.7 ns
Output Function AB
Compliance
RoHS Status Non-RoHS Compliant
