MC10H166FN
RoHS
/
Package 20-LCC (J-Lead)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
Contains Lead ECL J BEND Active High Magnitude Comparator 0C~75C 5V 3.7ns @ -5.2V - 1.27mm
PDF
/
Buying Options
Total Price: USD $8.9
Unit Price: USD $8.9015
≥1 USD $8.9015
≥10 USD $7.30455
≥100 USD $7.0756
≥500 USD $6.8476
≥1000 USD $6.6196
Inventory: 8103
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-LCC (J-Lead)
Number of Pins 20
Technical
Operating Temperature 0°C~75°C
Packaging Tube
Published 2006
Series 10H
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type Magnitude Comparator
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature TWO OUTPUT PROVIDES: A < B; A > B AND A = B FUNCTIONS
Subcategory Arithmetic Circuits
Technology ECL
Voltage - Supply -4.94V~-5.46V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 10H166
Output Active High
Pin Count 20
Qualification Status Not Qualified
Power Supplies 5V
Output Current 50mA
Max Supply Current 117mA
Number of Bits 5
Propagation Delay 3.7 ns
Response Time 1.6 ns
Family 10H
Current - Output High, Low 50mA 50mA
Max Propagation Delay @ V, Max CL 3.7ns @ -5.2V, -
Output Function AB
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
