LA72912V-TLM-H
RoHS
RoHS compliant
RoHS compliantPackage 24-LSSOP (0.220, 5.60mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Modulator Demodulator Tape & Reel (TR) Surface Mount Video video processing unit 1.3mm 5.5V 13.5MHz 32mW
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.4561
≥1 USD $3.4561
≥10 USD $2.8367
≥100 USD $2.7474
≥500 USD $2.65905
≥1000 USD $2.5707
Inventory: 10358
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.6mm
Length 7.8mm
Height 1.3mm
Technical
Halogen Free Halogen Free
Min Supply Voltage 4.7V
Max Supply Voltage 5.5V
Temperature Grade OTHER
Operating Supply Voltage 5V
Pin Count 24
Frequency 13.5MHz
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 32mW
Applications Video
Min Operating Temperature -30°C
Max Operating Temperature 70°C
Terminal Finish Tin/Bismuth (Sn/Bi)
Type Modulator, Demodulator
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e6
Published 2008
Packaging Tape & Reel (TR)
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-LSSOP (0.220, 5.60mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 2 Weeks
