FMS6501MSA28
RoHS
/
Package 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Video Switch 12-Input 9-Output Tube FMS6501 Surface Mount video processing unit 1.85mm 5.25V 90MHz 85C
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.52095
≥1 USD $1.52095
≥10 USD $1.2483
≥100 USD $1.20935
≥500 USD $1.1704
≥1000 USD $1.13145
Inventory: 8544
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.6mm
Length 10.5mm
Height 1.85mm
Technical
Bandwidth 90MHz
Number of Channels 12
Supply Voltage-Min (Vsup) 3.135V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 5.25V
Base Part Number FMS6501
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Applications Set-Top Boxes
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type Video Switch, 12-Input 9-Output
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Physical
Number of Pins 28
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
