TSM972CUA+T
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Cut Tape (CT) CMOS TTL TSM97x Obsolete comparator circuit 5nA 12mus 50mV 67dB
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.36432
≥100 USD $0.356928
≥500 USD $0.349958
≥1000 USD $0.346509
Inventory: 1150
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Supplier Device Package 8-MSOP
Technical
Operating Temperature 0°C~70°C
Packaging Cut Tape (CT)
Published 2015
Series TSM97x
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type General Purpose
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Output Type CMOS, TTL
Number of Elements 2
Max Supply Voltage 11V
Min Supply Voltage 2.5V
Output Current 40mA
Propagation Delay 12 μs
Quiescent Current 4μA
Common Mode Rejection Ratio 67 dB
Voltage - Supply, Single/Dual (±) 2.5V~11V ±1.25V~5.5V
Input Offset Voltage (Vos) 10mV
Power Supply Rejection Ratio (PSRR) 67dB
Max Dual Supply Voltage 5.5V
Min Dual Supply Voltage 1.25V
Max Input Current 5nA
Input Bias Current 5nA
Current - Quiescent (Max) 4μA
Voltage - Input Offset (Max) 10mV @ 2.5V
Current - Input Bias (Max) 0.005μA @ 2.5V
Hysteresis 50mV
CMRR, PSRR (Typ) 67dB CMRR, 67dB PSRR
Current - Output (Typ) 40mA
Propagation Delay (Max) 12μs
Compliance
RoHS Status RoHS Compliant
