TLV1391CDBVRG4
RoHS
/
Package SOT-23-5
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) OPEN-COLLECTOR 0.4muA Nickel/Palladium/Gold (Ni/Pd/Au) comparator circuit 250nA 180ns 2.9mm 5mV
PDF
/
Buying Options
Total Price: USD $0.25
Unit Price: USD $0.248074
≥1 USD $0.248074
≥10 USD $0.234039
≥100 USD $0.220789
≥500 USD $0.208284
≥1000 USD $0.196503
Inventory: 1713
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOT-23-5
Number of Pins 5
Weight 15.790684mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Subcategory Comparator
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Pin Count 5
Output Type OPEN-COLLECTOR
Temperature Grade COMMERCIAL
Number of Channels 1
Max Supply Voltage 7V
Min Supply Voltage 2V
Nominal Supply Current 150μA
Max Supply Current 150μA
Current - Output 20mA
Quiescent Current 175μA
Response Time 180 ns
Amplifier Type COMPARATOR
Current - Input Bias 250nA
Output Current per Channel 600μA
Input Offset Voltage (Vos) 5mV
Average Bias Current-Max (IIB) 0.4μA
Max Input Current 250nA
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
