LM239PWE4
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / Linear - Comparators
Description
TSSOP TTL Nickel/Palladium/Gold (Ni/Pd/Au) e4 comparator circuit 0.25muA 1.3mus 5mm 5mV
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.90502
≥1 USD $5.90502
≥10 USD $5.570783
≥100 USD $5.255451
≥500 USD $4.957975
≥1000 USD $4.677333
Inventory: 8552
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 5mm
Height Seated (Max) 1.2mm
Technical
Bias Current-Max (IIB) @25C 0.25μA
Min Dual Supply Voltage 1V
Max Dual Supply Voltage 15V
Voltage Gain 106.02dB
Input Offset Voltage (Vos) 5mV
Output Current per Channel 6mA
Current - Input Bias 250nA
Amplifier Type COMPARATOR
Response Time 1.3 μs
Quiescent Current 2mA
Current - Output 20mA
Max Supply Current 2mA
Nominal Supply Current 2mA
Min Supply Voltage 2V
Max Supply Voltage 30V
Number of Channels 4
Temperature Grade OTHER
Power Supplies 5V
Output Type TTL
Pin Count 14
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Comparator
Min Operating Temperature -25°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Physical
Weight 57.209338mg
Number of Pins 14
Package / Case TSSOP
Mount Surface Mount
