KA239D
RoHS
/
Package SOP
Category Integrated Circuits (ICs) / Linear - Comparators
Description
COMPARATOR RoHS Compliant GULL WING OTHER comparator circuit 85C 570mW 9000muV 8.56mm
PDF
/
Inventory: 4616
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.95mm
Length 8.56mm
Height Seated (Max) 1.8mm
Technical
Input Offset Voltage-Max 9000μV
Bias Current-Max (IIB) @25C 0.25μA
Current - Input Bias 250nA
Amplifier Type COMPARATOR
Response Time 1.3 μs
Current - Output 18mA
Max Supply Current 2mA
Nominal Supply Current 1.1mA
Power Dissipation-Max 570mW
Min Supply Voltage 18V
Max Supply Voltage 36V
Number of Channels 4
Temperature Grade OTHER
Power Supplies 5V
Output Type OPEN-COLLECTOR
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Comparator
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e3
Physical
Surface Mount YES
Package / Case SOP
