A80C186XL20
RoHS
/
Package /
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
IC MPU I186 20MHZ 68CPGA
PDF
/
Buying Options
Total Price: USD $76.04
Unit Price: USD $76.0361
≥1 USD $76.0361
≥10 USD $62.3884
≥100 USD $60.439
≥500 USD $58.4896
≥1000 USD $56.53925
Inventory: 703
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Number of Pins 68
Technical
Packaging Bulk
Number of Terminations 68
ECCN Code 3A991.A.2
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS; NUMERIC COPROCESSOR INTERFACE
HTS Code 8542.31.00.01
Subcategory Microprocessors
Technology CMOS
Terminal Position PERPENDICULAR
Terminal Form PIN/PEG
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 20MHz
Pin Count 68
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade COMMERCIAL
Voltage 5V
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
uPs/uCs/Peripheral ICs Type MICROPROCESSOR
Supply Current-Max 90mA
Bit Size 16
Access Time 20 μs
Address Bus Width 20
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 16
Format FIXED POINT
Integrated Cache NO
RAM (words) 0
Number of External Interrupts 5
Number of DMA Channels 2
Dimensions
Height Seated (Max) 5.21mm
Length 29.464mm
Width 29.464mm
Compliance
RoHS Status RoHS Compliant
