ISO224ADWVR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
Reinforced isolated amplifier for voltage sensing with ±12-V input 8-SOIC -55 to 125
PDF
/
Buying Options
Total Price: USD $11.72
Unit Price: USD $11.7216
≥1 USD $11.7216
≥10 USD $10.77648
≥100 USD $10.32944
≥500 USD $9.101048
≥1000 USD $8.654342
≥3000 USD $8.095982
Inventory: 1142
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Type Isolated
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Automotive
Subcategory Isolation Amplifier
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code compliant
Base Part Number ISO224
JESD-30 Code R-PDSO-G8
Operating Temperature (Max) 125°C
Operating Temperature (Min) -55°C
Temperature Grade MILITARY
Supply Voltage Limit-Max 26V
-3db Bandwidth 185MHz
Isolation Voltage-Min 2121V
Dimensions
Height Seated (Max) 2.8mm
Length 7.5mm
Width 5.85mm
Compliance
RoHS Status RoHS Compliant
