LTC6406CMS8E#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
IC ADC DRIVER 8MSOP
PDF
/
Buying Options
Total Price: USD $8.71
Unit Price: USD $8.712
≥1 USD $8.712
≥10 USD $7.87336
≥100 USD $7.506752
≥500 USD $6.518072
≥1000 USD $6.225155
≥3000 USD $5.675877
Inventory: 1149
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 3mm
Technical
Nominal Gain Bandwidth Product 3 GHz
Input Bias Current 17μA
Power Supply Rejection Ratio (PSRR) 55dB
Average Bias Current-Max (IIB) 24μA
Unity Gain BW-Nom 3000000 kHz
Gain Bandwidth Product 3 GHz
Bandwidth 3 GHz
Input Offset Voltage (Vos) 1mV
Common Mode Rejection Ratio 50 dB
Slew Rate 630 V/μs
Min Supply Voltage 2.7V
Max Supply Voltage 3.5V
Number of Channels 1
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3V
Qualification Status Not Qualified
Pin Count 8
Base Part Number LTC6406
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Operational Amplifier
Applications Data Acquisition
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Matte Tin (Sn)
Resistance 130kOhm
Type ADC Driver
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 months ago)
Factory Lead Time 8 Weeks
