V62/08618-01XE
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Lead Free GULL WING OPERATIONAL AMPLIFIER CMOS op amp buffer circuit 78dB 6V/mus 125C 5.5MHz
PDF
/
Inventory: 5854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Package / Case SOT-23
Surface Mount YES
Number of Pins 5
Technical
Packaging Tape and Reel
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 2
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Operational Amplifier
Packing Method TR
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Pin Count 5
Temperature Grade MILITARY
Number of Channels 1
Max Supply Voltage 5V
Min Supply Voltage 2.7V
Slew Rate 6 V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type OPERATIONAL AMPLIFIER
Common Mode Rejection Ratio 78 dB
Current - Input Bias 500pA
Input Offset Voltage (Vos) 500μV
Gain Bandwidth Product 5.5MHz
Unity Gain BW-Nom 5500 kHz
Voltage Gain 124dB
Low-Offset NO
Frequency Compensation YES
Low-Bias YES
Micropower NO
Programmable Power NO
Max I/O Voltage 500μV
Wideband NO
Power NO
Input Offset Current-Max (IIO) 0.0006μA
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
