TLC2264MWB
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead FLAT OPERATIONAL AMPLIFIER CMOS op amp amplifier circuit 70dB 0.55V/us 125C 710kHz
PDF
/
Inventory: 6777
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 9.21mm
Height Seated (Max) 2.03mm
Technical
Slew Rate-Min 0.3 V/us
Input Offset Voltage-Max 3000μV
Min Dual Supply Voltage 2.2V
Micropower YES
Low-Bias YES
Max Dual Supply Voltage 8V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.0008μA
Voltage Gain 114.81dB
Unity Gain BW-Nom 730 kHz
Neg Supply Voltage-Nom (Vsup) -5V
Gain Bandwidth Product 710 kHz
Common Mode Rejection Ratio 70 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.55 V/us
Supply Current-Max 1mA
Min Supply Voltage 4.4V
Max Supply Voltage 16V
Number of Channels 4
Temperature Grade MILITARY
Pin Count 14
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Terminal Form FLAT
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Subcategory Operational Amplifier
Min Operating Temperature -55°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 14
Pbfree Code no
Physical
Number of Pins 14
Mount Surface Mount
