TL343IDBVRE4
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TL343 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 2.9mm 0.8muA 10mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.84645
≥1 USD $0.84645
≥10 USD $0.69445
≥100 USD $0.6726
≥500 USD $0.65075
≥1000 USD $0.6289
Inventory: 1179
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Max I/O Voltage 10mV
Nominal Gain Bandwidth Product 1MHz
Voltage - Input Offset 2mV
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.8μA
Voltage Gain 106.02dB
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Input Offset Voltage (Vos) 10mV
Output Current per Channel 30mA
Voltage - Supply, Single/Dual (±) 3V~30V ±1.5V~15V
Current - Input Bias 200nA
Common Mode Rejection Ratio 70 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 1V/μs
Nominal Supply Current 2.8mA
Operating Supply Current 700μA
Number of Elements 1
Operating Supply Voltage 15V
Pin Count 5
Base Part Number TL343
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
