TL032ACD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 TL032 Nickel/Palladium/Gold (Ni/Pd/Au) op amp buffer circuit 4.9mm 0.0004muA 9V 1100kHz
PDF
/
Buying Options
Total Price: USD $2.71
Unit Price: USD $2.7104
≥1 USD $2.7104
≥10 USD $2.43056
≥100 USD $2.297742
≥500 USD $1.991378
≥1000 USD $1.889272
Inventory: 451
Minimum: 1
-
+
Technical Details
Technical
Supply Voltage 5V
Base Part Number TL032
Pin Count 8
Operating Supply Voltage 15V
Number of Elements 2
Operating Supply Current 434μA
Nominal Supply Current 560μA
Output Current 40mA
Slew Rate 5.1V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type J-FET
Common Mode Rejection Ratio 75 dB
Current - Input Bias 2pA
Voltage - Supply, Single/Dual (±) 10V~30V ±5V~15V
Output Current per Channel 40mA
Input Offset Voltage (Vos) 390μV
Bandwidth 1.1MHz
Neg Supply Voltage-Nom (Vsup) -5V
Unity Gain BW-Nom 1100 kHz
Voltage Gain 81.58dB
Average Bias Current-Max (IIB) 0.0004μA
Low-Offset NO
Frequency Compensation YES
Low-Bias YES
Micropower YES
Programmable Power NO
Dual Supply Voltage 9V
Nominal Gain Bandwidth Product 1.1MHz
Max I/O Voltage 800μV
Power NO
Input Offset Current-Max (IIO) 0.0001μA
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIFET
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
