LMV822DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead GULL WING Rail-to-Rail Surface Mount General Purpose Amplifier 72dB 1.9V/mus -40C~85C 5.5MHz
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.0735
≥1 USD $1.0735
≥10 USD $0.88065
≥100 USD $0.8531
≥500 USD $0.82555
≥1000 USD $0.798
Inventory: 22797
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 2.7V
Base Part Number LMV822
Pin Count 8
Output Type Rail-to-Rail
Number of Channels 2
Operating Supply Current 500μA
Nominal Supply Current 700μA
Output Current 45mA
Slew Rate 1.9V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 72 dB
Current - Input Bias 40nA
Voltage - Supply, Single/Dual (±) 2.5V~5.5V ±1.25V~2.75V
Output Current per Channel 45mA
Input Offset Voltage (Vos) 3.5mV
Bandwidth 5.5MHz
Unity Gain BW-Nom 5000 kHz
Voltage Gain 105dB
Average Bias Current-Max (IIB) 0.14μA
Low-Offset NO
Frequency Compensation YES
Supply Voltage Limit-Max 5.5V
Voltage - Input Offset 1mV
Low-Bias NO
Micropower YES
Bias Current-Max (IIB) @25C 0.1μA
Programmable Power NO
Power NO
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
