LM348DRG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 LM348 Nickel/Palladium/Gold (Ni/Pd/Au) op amp amplifier circuit 8.65mm 0.2muA 9V 1000kHz
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.26125
≥1 USD $0.26125
≥10 USD $0.2147
≥100 USD $0.20805
≥500 USD $0.2014
≥1000 USD $0.19475
Inventory: 1184
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Input Offset Current-Max (IIO) 0.05μA
Power NO
Dual Supply Voltage 9V
Programmable Power NO
Bias Current-Max (IIB) @25C 0.2μA
Micropower NO
Low-Bias NO
Voltage - Input Offset 1mV
Frequency Compensation YES
Low-Offset NO
Voltage Gain 104.08dB
Unity Gain BW-Nom 1000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 1MHz
Input Offset Voltage (Vos) 6mV
Output Current per Channel 25mA
Voltage - Supply, Single/Dual (±) 8V~36V ±4V~18V
Current - Input Bias 30nA
Common Mode Rejection Ratio 70 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.5V/μs
Output Current 25mA
Nominal Supply Current 2.4mA
Operating Supply Current 2.4mA
Power Supplies +-15V
Number of Elements 4
Operating Supply Voltage 18V
Pin Count 14
Base Part Number LM348
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Operational Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
