MC33079PG
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
RoHS Compliant EAR99 MC33079 Tin (Sn) op amp buffer circuit 19.56mm 0.8muA 9V 9000kHz
PDF
/
Buying Options
Total Price: USD $3.76
Unit Price: USD $3.75915
≥1 USD $3.75915
≥10 USD $3.08465
≥100 USD $2.98775
≥500 USD $2.8918
≥1000 USD $2.79585
Inventory: 1006
Minimum: 1
-
+
Technical Details
Technical
Voltage Gain 110dB
Average Bias Current-Max (IIB) 0.8μA
Power Supply Rejection Ratio (PSRR) 80dB
Low-Offset NO
Frequency Compensation YES
Voltage - Input Offset 150μV
Bias Current-Max (IIB) @25C 0.75μA
Dual Supply Voltage 9V
Nominal Gain Bandwidth Product 16MHz
Unity Gain BW-Nom 9000 kHz
Neg Supply Voltage-Nom (Vsup) -15V
Bandwidth 16MHz
Input Offset Voltage (Vos) 2.5mV
Output Current per Channel 37mA
Halogen Free Halogen Free
Voltage - Supply, Single/Dual (±) 10V~36V ±5V~18V
Current - Input Bias 300nA
Common Mode Rejection Ratio 80 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 7V/μs
Output Current 29mA
Nominal Supply Current 8.4mA
Operating Supply Current 8.4mA
Number of Channels 4
Power Supplies +-15V
Operating Supply Voltage 18V
Pin Count 14
Base Part Number MC33079
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 15V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Height 3.68mm
Length 19.56mm
Width 6.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Weight 4.535924g
Number of Pins 14
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 19 hours ago)
Factory Lead Time 4 Weeks
