MCP6001T-I/OT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant EAR99 MCP6001 Tape & Reel (TR) op amp amplifier circuit 3.1mm 1pA 4.5mV 1000kHz
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.2112
≥100 USD $0.1936
Inventory: 84058
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.8mm
Length 3.1mm
Height 1.3mm
Technical
Programmable Power NO
Micropower YES
Low-Bias YES
Frequency Compensation YES
Low-Offset NO
Power Supply Rejection Ratio (PSRR) 86dB
Voltage Gain 112dB
Unity Gain BW-Nom 1000 kHz
Bandwidth 1MHz
Input Offset Voltage (Vos) 4.5mV
Output Current per Channel 23mA
Voltage - Supply, Single/Dual (±) 1.8V~6V
Current - Input Bias 1pA
Common Mode Rejection Ratio 60 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 0.6V/μs
Output Current 23mA
Nominal Supply Current 100μA
Operating Supply Current 100μA
Voltage 6V
Number of Channels 1
Operating Supply Voltage 5.5V
Output Type Rail-to-Rail
Pin Count 5
Base Part Number MCP6001
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
