MAX409BESA+T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant R-PDSO-G8 MAX409 Matte Tin (Sn) op amp amplifier circuit 4.9mm 0.00005muA 750muV 150kHz
PDF
/
Buying Options
Total Price: USD $11.47
Unit Price: USD $11.47212
≥1 USD $11.47212
≥200 USD $4.578082
≥500 USD $4.424473
≥1000 USD $4.349638
Inventory: 1238
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2003
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Operational Amplifier
Packing Method TAPE AND REEL
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Base Part Number MAX409
Pin Count 8
JESD-30 Code R-PDSO-G8
Output Type Rail-to-Rail
Operating Supply Voltage 5V
Number of Circuits 1
Operating Supply Current 1μA
Nominal Supply Current 1.2mA
Output Current 600μA
Slew Rate 0.08V/μs
Architecture VOLTAGE-FEEDBACK
Amplifier Type General Purpose
Common Mode Rejection Ratio 60 dB
Current - Input Bias 0.1pA
Voltage - Supply, Single/Dual (±) 2.5V~10V
Output Current per Channel 600μA
Input Offset Voltage (Vos) 750μV
Gain Bandwidth Product 150kHz
Neg Supply Voltage-Nom (Vsup) -2.5V
Unity Gain BW-Nom 150 kHz
Voltage Gain 120dB
Average Bias Current-Max (IIB) 0.00005μA
Low-Offset NO
Low-Bias YES
Micropower YES
Dimensions
Length 4.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
