LT1994HDD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
ROHS3Compliant S-PDSO-N8 LT1994 Matte Tin (Sn) op amp amplifier circuit 3mm 3muA -6.3V 70000kHz
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.04475
≥1 USD $3.04475
≥10 USD $2.4985
≥100 USD $2.41965
≥500 USD $2.34175
≥1000 USD $2.26385
Inventory: 35010
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 3mm
Height Seated (Max) 0.8mm
Technical
Neg Supply Voltage-Max (Vsup) -6.3V
Voltage - Input Offset 3mV
Supply Voltage Limit-Max 6.3V
Average Bias Current-Max (IIB) 3μA
Unity Gain BW-Nom 70000 kHz
Neg Supply Voltage-Nom (Vsup) -5V
Gain Bandwidth Product 70MHz
Voltage - Supply, Single/Dual (±) 2.375V~12.6V ±1.188V~6.3V
Current - Input Bias 18μA
Common Mode Rejection Ratio 85 dB
Amplifier Type Differential
Slew Rate 65V/μs
Current - Supply 14.8mA
Number of Circuits 1
Output Type Rail-to-Rail
Qualification Status Not Qualified
JESD-30 Code S-PDSO-N8
Pin Count 8
Base Part Number LT1994
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology BIPOLAR
Subcategory Operational Amplifier
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
