TPA6111A2DGN
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 TPA6111 Tube Depop Short-Circuit and Thermal Protection Shutdown audio amplifier 10mV 1.02mm 150mW x 2 @ 16Ohm 3.2mA
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.3992
≥1 USD $1.3992
≥10 USD $1.25752
≥100 USD $1.0109
≥500 USD $0.949247
≥1000 USD $0.830579
≥3000 USD $0.688195
Inventory: 139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount YES
Number of Pins 8
Weight 18.99418mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Feature Depop, Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Class AB
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Audio/Video Amplifiers
Max Power Dissipation 2.14W
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPA6111
Pin Count 8
Output Type Headphones, 2-Channel (Stereo)
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Number of Channels 2
Operating Supply Current 1.6mA
Nominal Supply Current 3.2mA
Power Dissipation 2.14W
Max Supply Current 3.2mA
Quiescent Current 1.6mA
Output Power 150mW
Supply Type Single
Input Offset Voltage (Vos) 10mV
Bandwidth 20 kHz
Power Supply Rejection Ratio (PSRR) 70dB
Max Output Power 150mW
Max Output Power x Channels @ Load 150mW x 2 @ 16 Ω
Harmonic Distortion 0.1%
Load Impedance 8 Ω
Dimensions
Height 1.1mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
