TAS5630BPHDR
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 TAS5630 Digi-Reel? Depop Differential Inputs Short-Circuit and Thermal Protection Shutdown audio amplifier 10.8V 1mm 480W x 1 @ 2Ohm; 300W x 2 @ 4Ohm 22.5mA
PDF
/
Buying Options
Total Price: USD $20.18
Unit Price: USD $20.18465
≥1 USD $20.18465
≥10 USD $16.56135
≥100 USD $16.04455
≥500 USD $15.5268
≥1000 USD $15.00905
Inventory: 1584
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 64-TQFP Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature 0°C~70°C TA
Packaging Digi-Reel?
Series PurePath? HD
JESD-609 Code e4
Feature Depop, Differential Inputs, Short-Circuit and Thermal Protection, Shutdown
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 64
ECCN Code EAR99
Type Class D
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.33.00.01
Max Power Dissipation 2.7W
Voltage - Supply 25V~52.5V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.8mm
Base Part Number TAS5630
Output Type 1-Channel (Mono) or 2-Channel (Stereo)
Operating Supply Voltage 52.5V
Supply Voltage-Max (Vsup) 13.2V
Supply Voltage-Min (Vsup) 10.8V
Number of Channels 4
Nominal Supply Current 22.5mA
Quiescent Current 13.3mA
Output Power 300W
Voltage Gain 23dB
Power Supply Rejection Ratio (PSRR) 80dB
Max Output Power 480W
Max Output Power x Channels @ Load 480W x 1 @ 2 Ω; 300W x 2 @ 4 Ω
Dimensions
Height 1.2mm
Length 14mm
Width 14mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
