LM4863N
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
Non-RoHS Compliant Contains Lead Through Hole Obsolete Amplifier IC Class AB -40C~85C TA 20kHz 1.5W 20mA
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.5224
≥1 USD $1.5224
Inventory: 522
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series Boomer?
JESD-609 Code e0
Feature Depop, Shutdown, Thermal Protection
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Class AB
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LM4863
JESD-30 Code R-PDIP-T16
Qualification Status Not Qualified
Output Type 2-Channel (Stereo) with Stereo Headphones
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2V
Number of Channels 2
Supply Current-Max 20mA
Output Power 1.5W
Bandwidth 20 kHz
Max Output Power 3.2W
Max Output Power x Channels @ Load 3.2W x 2 @ 3 Ω; 440mW x 2 @ 8 Ω
Harmonic Distortion 10%
Dimensions
Height Seated (Max) 5.08mm
Length 19.305mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
