LM4850MM/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
GULL WING ROHS3Compliant Surface Mount Obsolete Amplifier IC Class AB -40C~85C TA 20kHz 0.3W 7mA
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
Inventory: 2068
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Number of Pins 10
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series Boomer?
JESD-609 Code e3
Feature Depop, Shutdown, Thermal Protection
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Class AB
Terminal Finish Matte Tin (Sn)
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Technology CMOS
Voltage - Supply 2.4V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number LM4850
Pin Count 10
Qualification Status Not Qualified
Output Type 1-Channel (Mono) with Stereo Headphones
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2.7/5V
Supply Voltage-Min (Vsup) 2.4V
Number of Channels 2
Nominal Supply Current 7mA
Output Power 0.3W
Bandwidth 20 kHz
Max Output Power 1.9W
Max Output Power x Channels @ Load 1.9W x 1 @ 3 Ω; 300mW x 2 @ 8 Ω
Dimensions
Height Seated (Max) 1.1mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
