LM4780TA
RoHS
/
Package TO-220
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
RoHS Compliant Through Hole AUDIO AMPLIFIER Tin/Lead (Sn/Pb) audio amplifier 4Ohm 19V/mus 85C 8MHz
PDF
/
Buying Options
Total Price: USD $154.89
Unit Price: USD $154.8918
≥1 USD $154.8918
≥10 USD $149.72855
≥100 USD $134.23975
Inventory: 469
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 101.6mm
Length 152.4mm
Height 6.35mm
Technical
Load Impedance 4Ohm
Number of Amplifiers 2
Consumer IC Type AUDIO AMPLIFIER
Power - Output 60W
Dual Supply Voltage 28V
Min Dual Supply Voltage 10V
Max Dual Supply Voltage 42V
Power Supply Rejection Ratio (PSRR) 120dB
Voltage Gain 115dB
Gain Bandwidth Product 8MHz
Bandwidth 20 kHz
Input Offset Voltage (Vos) 10mV
Supply Type Dual, Single
Current - Input Bias 1μA
Common Mode Rejection Ratio 85 dB
Slew Rate 19 V/μs
Output Power 60W
Supply Current-Max 170mA
Power Dissipation 125W
Power Dissipation-Max 125W
Min Supply Voltage 20V
Max Supply Voltage 84V
Number of Channels 2
Temperature Grade OTHER
Power Supplies +-35V
Pin Count 3
Terminal Pitch 1mm
Number of Functions 1
Terminal Position ZIG-ZAG
Subcategory Audio/Video Amplifiers
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Physical
Weight 9.979032g
Number of Pins 27
Package / Case TO-220
Mount Through Hole
