RoHS
RoHS RoHS compliant
Package 27-Flexiwatt (Formed Leads)
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description ROHS3Compliant Through Hole Active Class AB audio amplifier -40C~105C TA 26dB 45W 45W x 2 @ 4Ohm
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.60374
≥1 USD $1.60374
≥10 USD $1.512965
≥100 USD $1.427329
≥500 USD $1.346532
≥1000 USD $1.270313
Inventory: 1146
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 27-Flexiwatt (Formed Leads)
Number of Pins 27

Technical

Operating Temperature -40°C~105°C TA
Packaging Tube
Feature Mute, Short-Circuit Protection, Standby
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Class AB
HTS Code 8542.33.00.01
Subcategory Audio/Video Amplifiers
Voltage - Supply 6V~18V
Terminal Position ZIG-ZAG
Number of Functions 2
Terminal Pitch 1mm
Base Part Number TDA7577
Output Type 2-Channel (Stereo)
Power Supplies 14.4V
Voltage Gain 26dB
Max Output Power 45W
Max Output Power x Channels @ Load 45W x 2 @ 4 Ω

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
