MAX9788ETI+T
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.39.00.01 MAX9788 Tape & Reel (TR) Depop Differential Inputs Shutdown audio amplifier 2.7V 4mm 2.4W x 1 @ 8Ohm 800mA
PDF
/
Buying Options
Total Price: USD $3.37
Unit Price: USD $3.3704
≥1 USD $3.3704
≥10 USD $3.02456
≥100 USD $2.859648
≥500 USD $2.478432
≥1000 USD $2.351325
≥3000 USD $2.109835
Inventory: 1348
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-WFQFN Exposed Pad
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Feature Depop, Differential Inputs, Shutdown
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Type Class G
HTS Code 8542.39.00.01
Subcategory Audio/Video Amplifiers
Max Power Dissipation 1.667W
Technology BICMOS
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.4mm
Base Part Number MAX9788
Pin Count 28
Output Type 1-Channel (Mono)
Max Output Current 800mA
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.6V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Nominal Supply Current 8mA
Quiescent Current 8mA
Output Power 2.4W
Common Mode Rejection Ratio 68 dB
Supply Type Single
Voltage Gain 12dB
Power Supply Rejection Ratio (PSRR) 77dB
Max Output Power 2.4W
Max Output Power x Channels @ Load 2.4W x 1 @ 8 Ω
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
