LT1123CZ#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear Regulator Controllers
Description
Tape & Reel (TR) LT1123 BIPOLAR Active linear regulator controller 700muA 0C~125C 5V
PDF
/
Buying Options
Total Price: USD $2.7
Unit Price: USD $2.70085
≥1 USD $2.70085
≥10 USD $2.21635
≥100 USD $2.147
≥500 USD $2.07765
≥1000 USD $2.0083
Inventory: 1100
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Technical
Operating Temperature 0°C~125°C
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Positive Fixed
Terminal Finish Matte Tin (Sn)
Technology BIPOLAR
Terminal Position BOTTOM
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT1123
Pin Count 3
JESD-30 Code O-PBCY-T3
Number of Outputs 1
Qualification Status Not Qualified
Current - Supply 700μA
Output Voltage 1 5V
Input Voltage (Min) 5.4V
Input Voltage (Max) 7.2V
Output Voltage1-Max 5.05V
Output Voltage1-Min 4.95V
Output Current1-Max 4A
Dropout Voltage1-Max 0.75V
Compliance
RoHS Status ROHS3 Compliant
