CS4525-CNZ
RoHS
/
Package 48-QFN
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
EAR99 CS4525 Tray ADC Depop I2C I2S Mute PWM Short-Circuit and Thermal Protection Volume Control audio amplifier 2.17V 850mum 30W x 1 @ 4Ohm; 15W x 2 @ 8Ohm 54mA
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4903
≥1 USD $3.4903
≥10 USD $2.86425
≥100 USD $2.77495
≥500 USD $2.68565
≥1000 USD $2.5954
Inventory: 1177
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-QFN
Number of Pins 48
Technical
Operating Temperature -10°C~70°C TA
Packaging Tray
Published 2001
Series Popguard?
Feature ADC, Depop, I2C, I2S, Mute, PWM, Short-Circuit and Thermal Protection, Volume Control
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Termination SMD/SMT
ECCN Code EAR99
Type Class D
Max Power Dissipation 180mW
Voltage - Supply 8V~18V
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Base Part Number CS4525
Pin Count 48
Output Type 2-Channel (Stereo) or 4-Channel (Quad)
Operating Supply Voltage 5V
Number of Channels 4
Nominal Supply Current 54mA
Number of Bits 24
Output Power 30W
Sampling Rate 0.096 MHz
Number of Analog In Channels 2
Output Bit Code BINARY, 2'S COMPLEMENT BINARY
Max Output Power 30W
Analog Input Voltage-Max 2.17V
Output Format PARALLEL, WORD
Max Output Power x Channels @ Load 30W x 1 @ 4 Ω; 15W x 2 @ 8 Ω
Load Impedance 4Ohm
Dimensions
Height 850μm
Length 9mm
Width 9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
