ADAU1592ACPZ-RL7
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
8542.33.00.01 ADAU1592 Tape & Reel (TR) Depop Mute Short-Circuit and Thermal Protection Standby audio amplifier 3V 7mm 24W x 2 @ 4Ohm 65mA
PDF
/
Buying Options
Total Price: USD $23.86
Unit Price: USD $23.85925
≥1 USD $23.85925
≥10 USD $19.57665
≥100 USD $18.96485
≥500 USD $18.35305
≥1000 USD $17.74125
Inventory: 1228
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1mm
Technical
Max Output Power x Channels @ Load 24W x 2 @ 4 Ω
Max Output Power 24W
Power Supply Rejection Ratio (PSRR) 65dB
Voltage Gain 37dB
Bandwidth 20 kHz
Supply Type Triple
Output Power 24W
Nominal Supply Current 65mA
Number of Channels 2
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.315V
Supply Voltage-Max (Vsup) 3.6V
Output Type 2-Channel (Stereo)
Pin Count 48
Base Part Number ADAU1592
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 9V~18V
Subcategory Audio/Video Amplifiers
HTS Code 8542.33.00.01
Type Class D
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature Depop, Mute, Short-Circuit and Thermal Protection, Standby
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 48
Package / Case 48-VFQFN Exposed Pad, CSP
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
