5700100111
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description
LED 3HI 2MM RED
PDF
/
Inventory: 6458
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.08mm
Length 14.4mm
Height 10.2mm
Technical
Number of LEDs 3
Wavelength - Peak 627nm
Illumination Color Red
Lens Type Diffused, Tinted
Luminous Intensity 15 mcd
Forward Voltage 2.8V
Lens Size 3mm T-1
Lens Style Round with Domed Top
Optoelectronic Device Type SINGLE COLOR LED ARRAY
Viewing Angle 70°
Current 20mA
Configuration 3 High
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.55mm
Number of Functions 3
Packing Method BAG
Subcategory Other Optoelectronics
HTS Code 8541.40.20.00
Voltage - Rated 2V
Color Red (x 3)
Terminal Finish Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Series 570
Published 2002
Packaging Bulk
Physical
Number of Pins 6
Mounting Type Through Hole, Right Angle
Mount PCB, Through Hole
