SPMWH3228FD7WAT0SG
RoHS
RoHS compliant
RoHS compliantPackage 1113 (2835 Metric)
Category Optoelectronics / LED Lighting - White
Description
LM281BZ+ 4000K SINGLE COLOR LED 90 LED Lighting series 3V 160mA 57lm 56lm~59lm 120°
PDF
/
Inventory: 5380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.030 0.75mm
Technical
Flux @ 25°C, Current - Test 57lm 56lm~59lm
Current - Max 160mA
CRI (Color Rendering Index) 90
CCT (K) 4000K
Lumens/Watt @ Current - Test 127 lm/W
Current - Test 150mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 3V
Color White, Neutral
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Size / Dimension 0.126Lx0.110W 3.20mmx2.80mm
Series LM281BZ+
Packaging Tape & Reel (TR)
Physical
Thermal Resistance of Package 25°C/W
Package / Case 1113 (2835 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
