L1Q0-5770000001300
RoHS
/
Package 1414 (3535 Metric)
Category Optoelectronics / LED Lighting - White
Description
LED LUXEON COOL WHITE 5700K 2SMD
PDF
/
Inventory: 1980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1414 (3535 Metric)
Supplier Device Package 3535
Thermal Resistance of Package 7°C/W
Technical
Packaging Cut Tape (CT)
Published 2013
Series LUXEON Q
Size / Dimension 0.136Lx0.136W 3.45mmx3.45mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Color White, Cool
Max Current Rating 1.05A
Voltage - Forward (Vf) (Typ) 2.81V
Viewing Angle 135°
Current - Test 350mA
Lumens/Watt @ Current - Test 129 lm/W
CCT (K) 5700K
CRI (Color Rendering Index) 70
Forward Voltage 2.81V
Current - Max 1.05A
Flux @ 85°C, Current - Test 127lm Typ
Dimensions
Height Seated (Max) 0.083 2.12mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
