PT-120-B-C11-EPC
RoHS
/
Package Module
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
PT-120 Flat LED Module With Connector LED Lighting COBs Engines Module 28mm 4.4V 36A 435lm Typ
PDF
/
Inventory: 2852
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Module
Technical
Published 2009
Series PT-120
Size / Dimension 28.00mm Lx42.00mm W
Feature With Connector
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type LED Module
Color Blue
Configuration Rectangle
Max Current Rating 36A
Voltage - Forward (Vf) (Typ) 4.4V
Current - Test 18A
Lens Style Flat
Lumens/Watt @ Current - Test 5 lm/W
Forward Voltage 4.4V
Current - Max 36A
Lens Type Flat
Temperature - Test 40°C
Flux @ Current/Temperature - Test 435lm Typ
Light Emitting Surface (LES) 2.60mm L x 4.63mm W
Wavelength 464nm
Dimensions
Height 5.61mm
Length 28mm
Width 42mm
Compliance
RoHS Status RoHS Compliant
