BXRE-30E2000-B-72
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
V13B WARM WHITE LED ARRAY
PDF
/
Inventory: 4944
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 1.70mm
Technical
Light Emitting Surface (LES) 14.00mm Dia
Flux @ Current/Temperature - Test 1960lm Typ
Temperature - Test 85°C
Lens Type Flat
Current - Max 900mA
CRI (Color Rendering Index) 80
CCT (K) 3000K 2-Step MacAdam Ellipse
Lumens/Watt @ Current - Test 143 lm/W
Current - Test 450mA
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 33.9V
Configuration Square
Color White, Warm
Type Chip On Board (COB)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 19.00mm Lx19.00mm W
Series Gen 7 V13 Array
Supply Chain
Factory Lead Time 4 Weeks
