APB2012CGKSEKC

Kingbright
RoHS
/
Package 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - SMD 2.0X1.2MM GRN/ORANGE SMD LED
PDF
/
Inventory: 8070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Height (Max) 1.10mm
Width 1.25mm
Length 2mm
Height 1.1mm

Technical

Wavelength - Dominant 570nm Green 601nm Orange
Lens Color Colorless
Wavelength - Peak 574nm Green 610nm Orange
Lens Transparency Clear
Millicandela Rating 50mcd Green, 180mcd Orange
Luminous Intensity 180 mcd
Forward Voltage 2.1V
Lens Size 1.30mmx1.25mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Orange
Viewing Angle 150°
Voltage - Forward (Vf) (Typ) 2.1V Green 2.1V Orange
Configuration Bidirectional
Case Code (Imperial) 0805
Case Code (Metric) 2012
Color Green, Orange
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 2.00mm Lx1.25mm W
Published 2012
Packaging Tape & Reel (TR)

Physical

Supplier Device Package Chip LED
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
