BXRC-35E2000-C-03
RoHS
/
Package Module
Category Optoelectronics / LED Lighting - COBs, Engines, Modules, Strips
Description
LED COB VERO13 WARM WHITE ROUND
PDF
/
Inventory: 7056
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 1.90mm
Technical
Light Emitting Surface (LES) 13.20mm Dia
Luminous Flux 1.87 klm
Flux @ Current/Temperature - Test 2020lm Typ
Temperature - Test 25°C
Lens Type Flat
Current - Max 1.05A
CRI (Color Rendering Index) 80
CCT (K) 3500K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test 124 lm/W
Current - Test 500mA
Forward Current 500mA
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 32.5V
Max Current Rating 1.5A
Voltage 32.7V
Configuration Round
Power Rating 16.4W
Color White, Warm
Type Chip On Board (COB)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 36.20mm Dia
Series Vero? 13 Array
Published 2013
Physical
Package / Case Module
