CMDA5BA7D1S
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE DIFFUSED 0805 SMD
PDF
/
Inventory: 9599
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 800μm
Technical
Reverse Voltage (DC) 5V
Reverse Voltage 5V
Wavelength - Peak 609nm
Lens Transparency Diffused
Millicandela Rating 90mcd
Luminous Intensity 90 mcd
Lens Size 1.40mmx1.25mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 170°
Voltage - Forward (Vf) (Typ) 1.9V
Power Dissipation 75mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0805
Case Code (Metric) 2012
Depth 1.25mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 75mW
Additional Feature SUPPORTS INFRARED
Color Orange
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 2.00mm Lx1.25mm W
Published 2012
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
