XZUYMG56W
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/YELLOW CLEAR 4SMD R/A
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.32736
≥100 USD $0.188056
≥500 USD $0.147189
Inventory: 1158
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case 3-SMD, No Lead
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2011
Size / Dimension 3.00mm Lx2.00mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 3
ECCN Code EAR99
Color Green, Yellow
HTS Code 8541.40.20.00
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 3.5mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2.2V Green 2.1V Yellow
Viewing Angle 140°
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Green 20mA Yellow
Lens Style Rectangle with Domed Top
Lens Size 2.00mmx1.00mm
Luminous Intensity 7 mcd
Millicandela Rating 14mcd Green, 7mcd Yellow
Lens Transparency Clear
Wavelength - Peak 565nm Green 590nm Yellow
Lens Color Colorless
Forward Current-Max 0.03A
Wavelength - Dominant 568nm Green 588nm Yellow
Dimensions
Height 1mm
Compliance
RoHS Status ROHS3 Compliant
