PG1112C-TR
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Green 0603 130/150° 7.6 mcd 2.2 V Diffused LED Surface Mount
PDF
/
Inventory: 1785
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 0.55mm
Width 800μm
Length 1.6mm
Height 550μm
Technical
Wavelength - Dominant 567nm
Wavelength 560 nm
Reverse Voltage 4V
Lens Color White
Wavelength - Peak 560nm
Lens Transparency Diffused
Millicandela Rating 7.6mcd
Luminous Intensity 7.6 mcd
Forward Voltage 2.2V
Lens Size 1.10mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 25mA
Viewing Angle 130°, 150°
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 70mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0603
Case Code (Metric) 1608
Depth 800μm
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Size / Dimension 1.60mm Lx0.80mm W
Series 1112C
Published 2010
Packaging Tape & Reel (TR)
Physical
Supplier Device Package 1608
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
