GM1JJ35200AE image
Favorite
GM1JJ35200AE image
Favorite
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED ORANGE CLEAR 0603 SMD
PDF
/
Inventory: 3243
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Height (Max) 0.40mm
Width 800μm
Length 1.6mm
Height 400μm

Technical

Wavelength - Dominant 618nm
Wavelength 627 nm
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 627nm
Lens Transparency Clear
Illumination Color Orange
Millicandela Rating 19mcd
Luminous Intensity 19 mcd
Forward Voltage 2V
Lens Size 1.00mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 5mA
Forward Current 20mA
Viewing Angle 150 °
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 52mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0603
Case Code (Metric) 1608
Depth 800μm
Color Orange
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Size / Dimension 1.60mm Lx0.80mm W
Published 2001
Packaging Tape & Reel (TR)

Physical

Supplier Device Package 1608
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
