GM1BC55250AC
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE CLEAR 0603 SMD
PDF
/
Inventory: 6737
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2002
Size / Dimension 1.60mm Lx0.80mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Max Operating Temperature 80°C
Min Operating Temperature -20°C
Color Blue
Power Rating 78mW
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 1.7mm
Reach Compliance Code unknown
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Current - Test 10mA
Lens Style Rectangle with Flat Top
Lens Size 1.00mmx0.80mm
Luminous Intensity 35 mcd
Lens Transparency Clear
Wavelength - Peak 470nm
Lens Color Colorless
Wavelength - Dominant 472nm
Dimensions
Height 650μm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
