SML312ECTT86
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE-GREEN CLEAR 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.0836
≥1 USD $0.0836
≥10 USD $0.0684
≥100 USD $0.0665
≥500 USD $0.0646
≥1000 USD $0.06175
Inventory: 1733
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2006
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Blue-Green
Subcategory Visible LEDs
Number of Functions 1
Base Part Number SML-312
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.3V
Viewing Angle 140 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.80mm
Luminous Intensity 200 mcd
Illumination Color Green
Lens Transparency Clear
Lens Color Colorless
Wavelength 525 nm
Wavelength - Dominant 527nm
Number of LEDs 1
Reverse Voltage-Max 5V
Dimensions
Height 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
