5988081107F
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.73566
≥1 USD $0.73566
≥10 USD $0.694017
≥100 USD $0.65474
≥500 USD $0.617675
≥1000 USD $0.582715
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.70mm
Technical
Reverse Voltage-Max 5V
Wavelength - Dominant 523nm
Overall Height 0.7mm
Forward Voltage-Max 3.5V
Forward Current-Max 0.02A
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 300mcd
Luminous Intensity 340.0 mcd
Lens Size 1.10mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.2V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Terminal Pitch 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature UL RECOGNIZED
Color Green
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.60mm Lx0.80mm W
Series 598
Published 2007
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
