SML-811UTT86
RoHS
RoHS compliant
RoHS compliantPackage 1305 (3412 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR 3412 SMD
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.32384
≥100 USD $0.214016
≥500 USD $0.165246
Inventory: 1595
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 1.15mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 620nm
Wavelength 630 nm
Lens Color Colorless
Lens Transparency Clear
Luminous Intensity 22.4 mcd
Lens Size 1.25mmx1.20mm
Lens Style Rectangle with Flat Top
Current - Test 10mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 145 °
Voltage - Forward (Vf) (Typ) 1.95V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Case Code (Imperial) 1305
Case Code (Metric) 3412
Terminal Pitch 3.3mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
Color Red
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.40mm Lx1.25mm W
Series SML-811
Published 2006
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 1305 (3412 Metric)
Mounting Type Surface Mount, Bottom Entry
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
