WP132XID
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED T-1 T/H
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.23936
≥100 USD $0.107448
≥500 USD $0.069326
≥1000 USD $0.062392
≥3000 USD $0.055458
Inventory: 20746
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Number of Pins 1
Technical
Packaging Bulk
Published 2007
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 2.54mm
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 3mm T-1
Luminous Intensity 25 mcd
Millicandela Rating 16mcd
Lens Transparency Diffused
Wavelength - Peak 627nm
Forward Voltage-Max 2.5V
Wavelength - Dominant 617nm
T-code T-1
Reverse Voltage-Max 5V
Dimensions
Height 5.2mm
Width 3.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
